Qhov Agilent B 2902 Lub Chaw Ntsuas Qhov Chaw Ntsuas / Kev ntsuas (SMU) yog qhov 2-channel, kev sib txig sib luag thiab tus nqi qis tshaj plaws SMU nrog cov peev txheej los ntsuas thiab ntsuas ob qhov hluav taws xob thiab tam sim no. Nws yog ntau yam ua I / V (tam sim no vs. voltage) ntsuas tau yooj yim nrog qhov tseeb. Kev sib xyaw ntawm 4 quadrant qhov chaw thiab ntsuas muaj peev xwm ua rau I / V ntsuas tau yooj yim thiab yooj yim yam tsis muaj teeb meem ntau yam twj paj nruag. Cov kev dav dav ntawm 210 V, 3 Ib qho DC / 10. 5 Ib qho xoos xaim uas siv ib qho cuab yeej tsuas yog txo qis kev nqis peev. Yam tsawg kawg nkaus 10 0 fA / 10 0 nV ntsuas kev ntsuas txhawb kev txhawb qhov tseeb ntawm DUT. Kev ua kom zoo dua 4. 3 '' xim tso saib thiab ntau hom pom txhim kho cov khoom tsim tau rau kev sim, debug thiab cim nrog kev ua haujlwm zoo.
Nta thiab Specifications ntawm:
2-channel
● Kev tsim tawm GUI los teeb tsa thiab saib I / V nkhaus rau ntawm pem hauv ntej vaj huam sib luag
Txhawb ob-channel kev teeb tsa
Source Yam tsawg kawg nkaus ntawm kev daws teeb meem: 1 pA / 1 µV
● Yam tsawg kawg nkaus kev ntsuas daws teeb meem: 100 fA / 100 nV
● Tshaj tawm ntau tshaj plaws: 210 V, 3 Ib qho DC / 10. 5 Ib qho mem tes
Generation Arbitrary waveform tiam thiab digitizing lub peev xwm los ntawm 20 µs luv
● Sib xyaw ua ke 4 qhov kawg ntawm qhov muaj peev xwm thiab ntsuas lub peev xwm
{The 4. 3 '' Cov duab xim txhawb pom cov qauv duab thiab cov lej ua kom pom
Free software software los pab txhawb PC-based ntsuas tswj hwm
Through High throughput thiab SCPI hais kom txhawb cov pa SMU cov lus txib teeb
